| Combination | Upper flute voices | Combi. Lever,
Memory 1-2-3 Preset 1.2.3.4, Volume (Levers) 16', 8', 6 2/5' , 5 1/3', 4', 2 2/3', 2', 1 3/5' |
| Lower flute voices | Combi. Lever,
Memory 1-2-3 Preset 1.2.3.4, Volume (Levers) 16', 8', 6 2/5' , 5 1/3', 4', 2 2/3', 2', 1' Attack 4', 2 2/3', Attack Length |
|
| Pedals | Combi. Lever,
Memory 1-2, Volume (Levers 16', 8', 4' |
|
| Orchestra | Upper | Strings 1,
Strings 2, Strings 3, Strings 4, Brass 1, Brass 2, Brass 3, Reed 1, Reed2 , Vocal, Spice
1, Spice 2 (Controls) Preset Vibrato, Touch Tone, Volume |
| Lower | Strings 1,
Strings 2, Strings 3, Brass 1, Brass 2, Brass 3, Reed, Vocal 1, Vocal 2, Spice 1,
Spice 2, Cosmic (Controls) Preset Vibrato, Touch Tone, Volume |
|
| Special Presets | Upper | Piano,
Harpsichord, Celesta, Vibraphone, Marimba, Mandolin, Banjo, Jazz Guitar, Brass 1, Brass 2,
Cosmic (Control) Touch Tone, Volume |
| Lower | Piano,
Electric Piano, Harpsichord, Harp, Acoustic Guitar, Jazz Guitar, Brass 1, Brass 2, Cosmic
1, Cosmic 2, Cosmic3 (Control) Touch Tone, Volume |
|
| Custom Voices | Upper/Lower | Flute, Oboe,
Clarinet, Saxophone, Trumpet, Trombone, Violin, Jazz Guitar, Hawaiian Guitar, Bass Guitar, Vocal, Cosmic 1, Cosmic 2, Cosmic 3, Cosmic4 (Controls) Preset Vibrato, Touch Vibrato, Touch Tone Volume |
| Pedals | Contra Bass 1,
Contra Bass 2, Contra Bass 3, Contra Bass 4, Tuba, Electric Bass 1, Electric Bass 2,
Electric Bass 3, Vocal, Cosmic (Controls) Brilliance, Volume |
|
| Solo | Piccolo, Flute, Oboe,
Clarinet, Saxophone, Trumpet 1, Trumpet 2, Horn, Trombone, Violin, Cello, Jazz
Guitar, Harmonica, Vocal, Cosmic 1, Cosmic 2 (Controls) Detune, Coupler, Transposition (down, normal, up) Preset Vibrato, Touch Vibrato, Touch Tone, Brilliance, Volume, Slide Control |
|
| Ensemble | Upper Combi, Upper Orchestra, Upper Special, Upper Custom, Lower Combi, Lower Orchestra, Lower Special, Lower Custom | |
| Effects Controls | Sustain | (Switches) Upper Sustain (knee) Lower Sustain
(knee), Pedal Sustain |
| Symphonic | Celeste, Symphonic, Upper Combi, Upper Orchestra, Lower Combi, Lower Orchestra, | |
| Tremolo | Chorus, Tremolo, Upper Combi, Upper Orchestra, Lower Combi, Lower Orchestra, Tremolo Speed control, Reverb, Glide (foot switch control), Pedal Dynamic Range Control, (combination) Program Set, Response Fast, Timbre Variation | |
| Vibrato Presetter | Set, Lever, Player, Preset (Controls) Touch depth, Delay, Depth, Speed (Indicator) Solo, Upper Orchestra, U/L Custom, Lower Orchestra, Pedals |
|
| Auto Rhythm | Pattern Selectors | March, Waltz, Ballad, Swing, Bounce, Slow
Rock, 8 Beat 1, 8 Beat 2, Tango, Latin 1, Latin 2, Bossanova, Samba, Latin Rock, Disco, 16 Beat, Variation 1-2-3-4 |
| Break Variation | 1-2-3 (16x3 patterns), Break, Break Variation (foot switch control) | |
| Auto Rhythm | Normal, 4 Bar, 8 Bar, 16 Bar | |
| Rhythm Sequence Programmer | Program 1-2-3-4 (64 Bars x 4) On, Record, Blank, End, Back, Forward | |
| Digital Display | Tempo, Bar/Beat | |
| Controls | Syncro Start, Start, Tempo, Volume, Balance, Tempo Indicator Lamp, Rhythm Stop (foot switch control) | |
| Auto Arpeggio | Pattern Selectors | 1-2-3-4-5-6-7-8 (16x8 patterns) |
| Voice Selectors | Piano, Harpsichord, Strings, Harp, Volume (control) | |
| Rhythmic Chord | Pattern 1 | Piano, Jazz Guitar, Solid Guitar, Phaser (effect), Volume (control) |
| Pattern 2 | Brass, Jazz Guitar, Solid Guitar, Phaser (effect), Volume (control) | |
| Auto Bass/Chord | Mode Selectors | Normal, Single Finger Chord, Fingered Chord, Custom AB.C., Multi Bass (normal,1.2.3) Lower Memory, Pedal Memory |
| Play Assist | Functions | Melody on Chord 1, Melody on Chord 2, Duet, Counter Melody |
| Controls | Key Set (Duet Control), Play Assist (knee lever control) | |
| Voice Selectors | Upper Combi, Upper Orchestra, Upper Special | |
| Registration Memory | Preset Buttons | 1-2-3-4-5-6-7-8 |
| Controls | Memory, Cancel, Disable, Slider Drive, | |
| Registration Pack | Read, Confirm, Write, (indicator) Memory Ready, Error | |
| Main Controls | Manual Balance, Master Volume, Expression Pedal, Expression Pedal Display (On, Bright, 10 position), Reset, Knee Lever, Foot Switch, Power Switch, Power Light, Pitch Control. | |
| Other Fitting | Stereo-Headphone jack, Aux, Out Left-Right jacks, Aux. In Left-Right jacks, Exp. In jack, Yamaha Tone Cabinet connectors (13 pins - 13 pins), Leslie Tone Cabinet connector (11 pins), Remote (headphones), Registration Pack, Panel Light, Music Rest, Matching Bench, Rolltop Fallboard | |
| Main Amplifier | Center: 90w(rms), Left: 60w(rms), Right: 60w(rms) | |
| Speakers | Center | Woofer 36cm (14"), Mid-range 20cm (8"), Tweeter 5cm ( 2") |
| Left | Mid-range 20cm (8") Tweeter 5cm ( 2") | |
| Right | Mid-range 20cm (8") Tweeter 5cm ( 2") | |
| Circuitry | Solid State | (Incl. LSIs and ICs) |
| Power Consumption | - | |
| Power Source | 50/60Hz AC (240 volts - 620 watts) | |
| Dimensions | Cabinet | 135cm wide x 116cm deep x 116cm high (53 1/"4 inches w x 45 1/2 inches deep x 45 1/2 inches high) |
| Weight | Cabinet | 194kg (427 lbs.) (This is really heavy, it may take 4 people to lift it) |
| Bench | 18kg (40 lbs.) | |
| Finish | Real American Walnut |
